Electric 3 Phase Busbar Current Collector System Conductor Rail For Crane

Name: Electric 3 Phase Busbar Current Collector System Conductor Rail For Crane
Brand: qimei
Price: 1 USD

Place of Origin : Jiangsu, China

Brand Name : qimei

Model Number : HFP52

Packaging Details : Wooden pallet, wooden crate, according to customer's requirements

Supply Ability : 100000 Meter/Meters per Month

Color : copper color

Voltage : 220V/380V

Current : 50A-100A

Product Name : multipole enclosed conductor bus bar

Place of origin : China Jiangsu

Certificate : ISO CE CCC

Material : PVC+copper

Minimum order quantity : 1m

width*high : 52mm*87mm

Application : cranes,monorails,electric hoists,electric tools.stacki

Port : Shanghai

Contact Now

Good quality multipole enclosed 52 copper conductor bus bar

PRODUCT DISPLAY

Electric 3 Phase Busbar Current Collector System Conductor Rail For Crane

1. Safe and reliable, with IP 43 .
2. Waterproof and dustproof to prevent fingers from electric shock.
3. Energy saving and consumption reduction. The use of international conductive materials can reduce the power loss in the electric circuit to the greatest extent.
4. The maximum moving speed is 200m/min.
5. Easy to install and maintain.
6. Long service life, unique formula of conductor sheath, greatly increase the service life of the slide conductor system.
7. According to the working condition of the equipment, the bending and sliding wire system can be made.
8. The insulation sheath is added with anti-ULTRAVIOLET component, suitable for outdoor.
9. Provide standard PVC insulated sheathing and PPO heat-resistant insulated sheathing, suitable for different working environment.
10. The whole series of products can meet the VO extreme fire rating, -40 degree environmental requirements.

Product name:	multipole enclosed conductor bus bar
Product number:	HFP52
product material:	PVC+copper
Minimum quantity of product:	1m

MAIN PRODUCTS

COMPANY INFORMATION

FACTORY & WAREHOUSE

OUR CERTIFICATE

PACKAGE & TRANSPORT

FAQ

1.What the style of your company? Our company is a OEM factory , all the product made by ourselves, and we can control the schedule very well. 2.What do you need to provide a quote? Please kindly send us the picture of your product. Details below should be included: A.Model B. Materials C. Quantity D.Usage place ,etc. 3.How do I know about the production? During the massproduction, we will keep you informed of any process. Besides, we will do 100% quality inspection before shipment. 4.How do I know about the delivery ? We will inform you the tracking number once we get it from shipping agent. Also we will keep updating the latestshipping information for you. 5.What will you do for after sales? When our metal parts apply to your products, we will follow up and await your feedback. Any question related to ourmetal parts, our experienced engineers are ready to help.
